Drinking Water Coolers

Type

Bottle Filling Station with Bi-Level ADA Cooler Filtered Refrigerated Stainless 220V
Model: LZSTL8WSS3KSA

Description

Availability: Exclusively for Saudi Arabia.
Functionality: Combines a bottle filling station with a Bi-Level ADA-compliant water cooler.
Chilling Capacity: 30.28 liters per hour (LPH) at 10°C, based on 26.7°C inlet water and 32.2°C ambient temperature (ASHRAE 18 testing).
Power: 220V/60Hz.
Mounting: Wall-mounted, indoor use only.
Filtered: Certified to NSF 42 and 53 for reducing lead, cysts, chlorine, particulates, taste, and odor.
Certifications: NSF/ANSI 42, 53, 61, 372 (lead-free), and 401.
ADA & ICC A117.1 Compliance
Refrigeration System: 5-year limited warranty.

Data Sheet

Type

Bottle filling station with a single ADA-compliant water cooler.
Model: LZS8WSS3KSA

Description

Availability: Exclusively for Saudi Arabia.
Functionality: Combines a bottle filling station with a single ADA-compliant water cooler.
Chilling Capacity: 30.28 liters per hour (LPH) at 10°C, based on 26.7°C inlet water and 32.2°C ambient temperature (ASHRAE 18 testing).
Power: 220V/60Hz.
Mounting: Wall-mounted, indoor use only.
Filtered: Certified to NSF 42 and 53 for reducing lead, cysts, chlorine, particulates, taste, and odor.
Certifications: NSF/ANSI 42, 53, 61, 372 (lead-free), and 401.
ADA & ICC A117.1 Compliance
Refrigeration System: 5-year limited warranty.

Data Sheet

Type

In-Wall Bottle Filling Station with Mounting Frame Filtered Refrigerated Stainless
Model: LZWSM8K

Description

Functionality: Combines a bottle filling station with a filtered and refrigerated water cooler.
Chilling Capacity: 30.28 liters per hour (LPH) at 10°C, based on 26.7°C inlet water and 32.2°C ambient temperature (ASHRAE 18 testing).
Power: 115V/60Hz.
Mounting: Wall-mounted (in-wall frame/plate), indoor use only.
Fill Rate: 4.16 liters per minute (LPM).
Filtered: Certified to NSF 42 and 53 for reducing lead, cysts, chlorine, particulates, taste, and odor.
ADA & ICC A117.1 Compliance: Meets accessibility standards when installed correctly.
Certifications: NSF/ANSI 42, 53, 61, 372 (lead-free), and 401; UL 399; CAN/CSA C22.2 No. 120.
Refrigeration System: 5-year limited warranty.

Data Sheet

Type

Bottle Filling Station In-Wall Filtered Refrigerated Stainless 220V
Model LZWSM83K

Description

Functionality: In-wall bottle filling station with filtered and refrigerated water, designed for indoor use.
Chilling Capacity: 30.28 liters per hour (LPH) at 10°C, based on 26.7°C inlet water and 32.2°C ambient temperature (ASHRAE 18 testing).
Power: 220V/60Hz.
Mounting: Wall-mounted (in-wall frame/plate), indoor use only.
Filtered: Certified to NSF 42 and 53 for reducing lead, cysts, chlorine, particulates, taste, and odor.
ADA & ICC A117.1 Compliance: Meets accessibility standards when installed correctly.
Certifications: NSF/ANSI 42, 53, 61, 372 (lead-free), UL 399, CAN/CSA C22.2 No. 120, GreenSpec®.
Included Components: Bottle Filter (LZWSM83C), Filter (EWF3000), Chiller (ECH83), Mounting Frame (MFWS100).

Data Sheet

Type

Bottle Filling Station with Bi-Level Integral SwirlFlo® Fountain Filtered Refrigerated Stainless Model LZWS-LRPBM28K

Description

Functionality: Combines a bottle filling station with a bi-level SwirlFlo® fountain, offering filtered and refrigerated water.
Chilling Capacity: 30.28 liters per hour (LPH) at 10°C, based on 26.7°C inlet water and 32.2°C ambient temperature (ASHRAE 18 testing).
Power: 115V/60Hz.
Mounting: Wall-mounted (in-wall frame/plate), indoor use only.
Filtered: Certified to NSF 42 and 53 for reducing lead, cysts, chlorine, particulates, taste, and odor.
ADA & ICC A117.1 Compliance: Meets accessibility standards when installed correctly.
Certifications: NSF/ANSI 42, 53, 61, 372 (lead-free), and 401; UL 399; CAN/CSA C22.2 No. 120.
Refrigeration System: 5-year limited warranty.

Data Sheet

Type

Upper Bottle Filling Station Bi-Level Pedestal Non-Filtered Non-Refrigerated Model LK4420BF1U

Description

Functionality: Combines an upper bottle filling station with a bi-level pedestal fountain, designed for outdoor use.
Chilling Capacity: Non-refrigerated.
Power: No electrical required.
Mounting: Floor-mounted/freestanding, outdoor use only.
Stations Served: 2 (1 upper bottle filler, 1 lower bubbler).
Heavy Duty Vandal Resistant: Designed to withstand outdoor and high-traffic environments.
Laminar Flow: Ensures clean filling with minimal splash.
300 Series Stainless Steel: Durable and corrosion-resistant.
Mechanical Button Activation: Continues to supply water during service disruptions.

Finish Options: Black , Blue , Evergreen, Gray .

Data Sheet

Type

Remote Chiller Non-Filtered Refrigerated 8 GPH 220V Model ECH83SA

Description

Availability: Exclusively for Saudi Arabia.
Functionality: Remote electric refrigerated water chiller unit designed to provide chilled drinking water.
Chilling Capacity: 30.28 liters per hour (LPH) at 10°C, based on 26.7°C inlet water and 32.2°C ambient temperature (ASHRAE 18 testing).
Power: 220V/60Hz.
Mounting: Can be installed directly under a fountain or in a remote service area (within 15 feet recommended).
Stations Served: 1.
Certifications: NSF/ANSI 61 & 372 (lead-free), SASO IEC 60335-2-89 & 1062.
Operating Pressure: 40–105 psi.

Data Sheet

Type

SwirlFlo® Bi-Level Fountain Mechanical Bubbler Non-Filtered NonRefrigerated Stainless Model: EDFPB117C

Description

Functionality: Bi-Level Wall-Mounted Drinking Fountain
Mounting: Wall-mounted (on-wall installation). Requires In-Wall Carrier MPW200 (sold separately). Compatible with both indoor and outdoor environments.
Filtered: Optional filtration kit (EWF172) available separately.
ADA & ICC A117.1 Compliance: Meets accessibility standards when installed correctly.
Certifications: NSF/ANSI 42, 53, 61, 372 (lead-free), and 401; UL 399; CAN/CSA C22.2 No. 120.
